Panduit 12-fiber SFQ cassette, OS1/OS2, 9/125µm - FQ9N-12-10AF

Panduit 12-fiber SFQ cassette, OS1/OS2, 9/125µm - FQ9N-12-10AF

Upgrade your fiber optic network infrastructure with the Panduit Opticom Fiber Optic Drawer: Pre-Loaded 24 Duplex LC Multi-Mode OM3/4. Manufactured by Panduit, a trusted leader in network solutions, this drawer is designed to optimize fiber optic connectivity in data centers, telecommunications networks, and enterprise environments. With its pre-loaded configuration and 24 duplex LC connectors, it offers seamless and efficient connectivity for your critical applications.

Featuring multimode OM3/4 fiber type, this drawer ensures high-speed data transmission over short to medium distances, making it ideal for high-bandwidth applications. With 48 ports (24 duplex) and Aqua adapter color, it provides ample capacity and easy identification for organizing your fiber optic connections. The split sleeve material made of zirconia ensures precision and reliability in fiber optic alignment, minimizing signal loss and maximizing performance.

Features

• Pre-Loaded Configuration: Ready for immediate deployment, saving time and effort on installation.

• High Port Density: 48 ports (24 duplex) in a single rack space maximize rack efficiency and space utilization.

• Multimode Fiber: OM3/4 fiber type ensures high-speed data transmission for high-bandwidth applications.

• Aqua Adapter Color: Allows for easy identification and organization of fiber optic connections.

• Zirconia Split Sleeve: Ensures precise alignment and reliable connectivity, minimizing signal loss.

Specification

What Our Experts Think

• Optimized for High-Performance Networks: The Panduit 12-fiber SFQ Cassette (FQ9N-12-10AF) is specifically engineered for OS1/OS2 single-mode fiber networks, delivering low-loss, high-speed connectivity suitable for long-distance communication.
• Compact & Efficient: With a 12-fiber capacity, this cassette provides a space-saving solution for organizing and managing fiber connections while maximizing network density in data centers, telecom, or enterprise environments.
• Perfect for OS1/OS2 Applications: The 9/125µm fiber is ideal for high-speed, long-distance transmissions, ensuring optimal performance for a variety of critical applications, including backbone networks and fiber-to-the-premises (FTTP) deployments.
• Streamlined Installation & Management: The SFQ cassette is designed for easy installation and maintenance, making it an efficient choice for both initial deployment and ongoing network upgrades or troubleshooting.
• Durable & Reliable: Built with high-quality materials, the FQ9N-12-10AF cassette offers excellent durability, providing long-term reliability and minimizing the risk of performance degradation.

Q&A

Q: What is the Panduit 12-fiber SFQ Cassette, OS1/OS2, 9/125µm - FQ9N-12-10AF?
A: A 12-fiber optical cassette designed for OS1/OS2 single-mode fiber cables (9/125µm), providing a high-density, efficient solution for managing and connecting fiber optic networks.

Q: What are the key features?

• 12-Fiber Capacity: Supports up to 12 fiber connections in a single compact cassette, maximizing space efficiency.
• OS1/OS2, 9/125µm Compatibility: Designed for use with single-mode fiber, ideal for long-distance, high-performance network applications.
• High-Density Design: Efficiently manages multiple fiber connections in a small footprint, perfect for data centers and telecommunication infrastructure.
• Durable Construction: Ensures reliability and performance in demanding network environments.
• Easy Integration: Simplifies installation within Panduit fiber management systems, reducing setup time and complexity.

Q: Who is this cassette ideal for?
A: Ideal for network engineers and IT professionals working in data centers, telecommunications, and high-speed enterprise network environments that require reliable and scalable fiber optic connectivity.

Q: What makes it stand out?
A: Its high-density 12-fiber capacity combined with OS1/OS2 compatibility makes it an excellent choice for single-mode fiber networks requiring efficient, long-distance connections and minimal space usage.

Q: Is it easy to install?
A: Yes, the cassette is designed for easy integration into Panduit's fiber optic systems, ensuring a seamless and straightforward installation process.

Q: What applications is this cassette used for?
A: Used in high-speed, long-distance fiber optic networks, such as data centers, telecommunications systems, and fiber-to-the-premises (FTTP) solutions.

Maintenance Tips

• Regular Inspection:

  • Inspect the fiber optic cassette and its connectors regularly for any signs of damage, including cracks, scratches, or corrosion.
  • Check the fibers for any visible bends or stress, as sharp bends can cause signal degradation and performance issues.

• Clean Fiber Optic Connectors:

  • Keep the fiber connectors clean to ensure high-quality signal transmission. Use fiber optic cleaning tools, such as lint-free wipes and cleaning solutions specifically designed for fiber optics.
  • Avoid using abrasive materials or harsh chemicals that could damage the delicate fiber ends.

• Proper Storage and Handling:

  • Store the cassette in a clean, dry, and temperature-controlled environment to prevent contamination or environmental damage.
  • Always handle the cassette by its edges to avoid touching the fiber ends or connectors, which can cause dirt or scratches.

• Monitor Fiber Bend Radius:

  • Ensure that the fibers are not bent beyond their specified bend radius, as this can lead to performance loss or permanent damage to the fiber.
  • Avoid sharp bends and always use the appropriate cable management tools to maintain gentle, controlled fiber routing.

• Check for Dust and Contaminants:

  • Dust and other contaminants can negatively impact signal integrity. Inspect the cassette regularly for any signs of contamination, particularly around the connector ports.
  • Clean the cassette and connectors as needed using specialized fiber optic cleaning kits.

• Protect Against Moisture:

  • Keep the cassette dry, as exposure to moisture can cause fiber optic degradation and signal loss. Ensure that the cassette is stored in a dry location, away from humid environments or water sources.
  • Use moisture-resistant storage if the cassette is installed in areas prone to high humidity.

• Avoid Over-tightening Connections:

  • When making connections, avoid over-tightening the fiber optic connectors, as this can cause damage to the fiber or the connection ports.
  • Ensure connections are snug but do not force them, as fiber connectors are sensitive and can be easily damaged by excessive pressure.

• Test Signal Performance:

  • Perform regular performance tests to monitor the integrity of the fiber optic signal. If performance drops, inspect the fiber connectors for dirt, scratches, or other signs of damage.
  • Signal testing can help identify potential issues with the fibers or the cassette before they affect the overall system.

• Handle with Care During Installation and Maintenance:

  • During installation or maintenance, ensure the fiber optic cassette is properly supported and not subjected to physical stress. Avoid pulling or twisting the fiber cables as this can cause damage.
  • Ensure proper cable management is in place to maintain organized and safe routing.

• Professional Support for Major Issues:

  • If you encounter significant issues such as performance degradation or damaged fibers, seek professional help for inspection, cleaning, or replacement of damaged components.
  • Contact Panduit customer support for assistance or guidance if the cassette is damaged beyond repair or if you need replacement parts.
