U-Series 24" Gas Restaurant Range – Full 24" Griddle & Space-Saver Oven
Garland / U.S. Range • Model U24-G24L • 68,000 BTU
Fit a full-size griddle and a high-performance oven into just two feet of line space.
The Garland U-Series U24-G24L delivers griddle, roasting, finishing and holding
power in a single, all-stainless package that’s built for the rigours of
professional kitchens.
Why you’ll love it
-
All-day griddle performance – 24" (610 mm) wide, 5/8" (15 mm) smooth steel plate with manual Hi/Lo valves and a generous 23" (584 mm) working depth.
-
Even heat, fast recovery – Two cast-iron “H” style griddle burners (18,000 BTU each) plus a 32,000 BTU cast-iron oven burner for consistent results shift after shift.
-
Space-Saver oven – 13" H x 20" W x 26" D porcelain-lined cavity fits full-size sheet pans front-to-back; includes 3-position rack guides and one nickel-plated rack.
-
Snap-action thermostat – Modulating control from low to 500 °F (260 °C) for precise baking and finishing.
-
Built to last – Stainless steel front, sides, 5" plate rail, and a two-piece backguard with removable shelf for quick cleanup.
-
Easy on the line – Large, ergonomic control knobs and 6" (152 mm) stainless legs with adjustable feet for a perfect working height.
-
Simple serviceability – Front-serviceable components, separate gas regulator, and easy-access oven pilot.
-
Certified kitchen-ready – CSA Flame, CSA Star, cCSAus and NSF listed.
Technical specifications
| Overall width |
23 5⁄8" (600 mm) |
| Overall depth (to plate rail) |
34 1⁄2" (876 mm) |
| Work-top depth |
27" (686 mm) |
| Height (to shelf) |
57" (1448 mm) |
| Griddle plate |
24" W × 23" D × 5⁄8" thick smooth steel |
| Heat input – griddle |
36,000 BTU (2 × 18,000) |
| Heat input – oven |
32,000 BTU cast-iron “H” burner |
| Total heat input |
68,000 BTU (19.9 kW) |
| Oven interior (H × W × D) |
13" × 20" × 26" (330 × 508 × 660 mm) |
| Rack guides / racks supplied |
3 positions / 1 rack (nickel-plated) |
| Manifold pressure (Nat / LP) |
4.5" WC / 10" WC |
| Gas connection |
¾" NPT rear |
| Shipping weight |
367 lb (166 kg) |
Factory options & accessories
- Snap-action modulating griddle thermostat (175 – 425 °F).
- Low-profile 9 ⅜" (238 mm) backguard.
- Swivel or low-profile casters with front locks.
- Additional oven racks.
- Flanged deck-mount legs.
- Celsius temperature dials.
- Piezo spark ignition for griddle pilots.
Not for residential installation.
This commercial appliance must be installed in accordance with local codes and by a qualified professional.
Garland / U.S. Range reserves the right to modify specifications without notice.
